High Speed Net Making Machine With 500kg-800kg/24hrs Production Capacity

High Speed Net Making Machine With 500kg-800kg/24hrs Production Capacity

  • High Light

    net manufacturing machine

    ,

    raschel net machine

  • Features
    Open Cam Gearing And 3-roIlers Positive Yarn Let-off System
  • Application
    Knotless Fishing Net, Protecting Net, Purse Net And Shading Net
  • Gauge
    E6/E7/E8/E9/E12/E14
  • Working Width
    135-340"
  • Speed
    200-480rpm
  • Number Of Bars
    2-6
  • Place of Origin
    China
  • Brand Name
    Chenye
  • Certification
    SGS
  • Model Number
    SRCA
  • Minimum Order Quantity
    1 set
  • Price
    USD20000-50000
  • Packaging Details
    The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
  • Delivery Time
    45 WORKING DAYS
  • Payment Terms
    L/C, D/A, T/T, D/P, Western Union, MoneyGram
  • Supply Ability
    10 SETS PER MONTH

High Speed Net Making Machine With 500kg-800kg/24hrs Production Capacity

SRCA high speed single needle bar raschel machine for protecting net,sport net

WHAT KIND OF NETS CAN BE MADE

It's suitable for manufacturing knotless fishing net, protecting net, purse net, garment net and shading net.



Suitable Material :

HDPE ,polypropylene ,polyester

FEATURES

1.Model :single needle bar warp knitting machine

2. Needle type:Latch needle

3. Gauge:E6/E7/E8/E9/E12/E14 (needles/inch)

4. Working width: 135~340"

5. Number of guide bars: 2-6bars

6. Let -off mechanism: open cam gearing and 3-roller positive yarn let-off system.

7. Take-up: 2 rollers with friction drive, center shaft drive, 2 rollers with friction drive, separately-standing, center shat drive, separately-standing.

8. Max. speed of main shaft: working speed 200-530rpm

9. Drive motor: main drive motor is 3-11kw, slow speed motor is 0.37-1.5kw

10.Production Capacity: about 500kg-8000kg/24hrs

11.Weight :about 4500-14000/set

12.Packing:The machine is packed by port container, spare parts and control box are packed in cartons



Machine Advantage :

1.Simple structure, Operate Conveniently.

2.With automatic stop system

3.Cam drive ,stable performance

4.The main motor adopts conversion control , stepless Speed Regulating

5. Standard Fittings .

SPECIFICATION

Main type
Machine size
Weight(kg)
Main motor power
Inching motor power
Speed(rpm)
SRCA-135
4300*1700*2300
4500
3kw
0.37kw
200-530
SRCA-150
4900*1700*2300
5000
4kw
0.37kw
200-530
SRCA-180
6100*1700*2400
7500
5.5kw
0.75kw
200-530
SRCA-220
7300*1700*2400
9000
5.5kw
1.5kw
200-500
SRCA-260
8200*1700*2400
11000
7.5kw
1.5kw
200-480
SRCA-340
10300*1700*2400
14000
11kw
1.5kw
200-450

IMAGES

High Speed Net Making Machine With 500kg-800kg/24hrs Production Capacity 0

PACKAGING & SHIPPING

The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.



High Speed Net Making Machine With 500kg-800kg/24hrs Production Capacity 1High Speed Net Making Machine With 500kg-800kg/24hrs Production Capacity 2

OUR SERVICES

1. The warranty period of all products sold by our company is one year, with lifelong technical service support.

2. User's workers can get free technical training in our company to ensure correct usage and maintenance of equipment.

3. We will arrange special personnel for periodic visits and remind users to maintain the equipment regularly.

FAQ

1,Q:Are you a manufacturer or trade company?
A: We are a professional manufacturer holding our own international trade. For that we can better understand customer's needs and offer a reasonable price.

2,Q : Are you available for visiting the factory?
A : for long term business , we are really welcome all our friends to come here and visit our factory in order to On-the-spot investigation of our production capacity.

3,Q : Is the price changeable?
A : We offer reasonable price for every clients, and the price is changeable according to the purchase amounting.

4,Q : How about the quality?
A : Professional assembly line work and strict quality test system can ensure your high quality requirement.

5,Q : How about the after-sale service?
A : We offer after-sale overseas service. Engineers available to service machinery overseas.
