High-Speed Shade Net Making Machine with Customizable 135"-260" Width and Modern UV Protection Technology

1 set
MOQ
Negotiation
Price
High-Speed Shade Net Making Machine with Customizable 135"-260" Width and Modern UV Protection Technology
Features Gallery Product Description Request A Quote
Features
Specifications
Product Type: Shade Net Making Machine
Color: Customized
Working Width: 135"-260"
Speed: 200-450rpm
Size: 2m/2.5m/3.4m/3.8m/4.5m/5.5m/6m/6.6m/8.6m/9.6m/11m
Warranty: 1Year(lifelong Technical Support)
Basic Infomation
Place of Origin: China , Jiangsu
Brand Name: Chenye
Certification: ISO ,CE, TUV
Model Number: SRCA
Payment & Shipping Terms
Packaging Details: 40HQ/Set
Delivery Time: 60 days after deposit payment
Payment Terms: L/C,T/T,Western Union
Supply Ability: 25 sets per month
Product Description
High-Speed Greenhouse Protection With Modern Technology UV Protection Net
Product Overview
Number of bars: 2-8
Working Width: 135", 150", 170", 220", 240", 260"
Take-up manner: 2 rollers with friction drive, center shaft drive, separately-standing
Feature: The machine is equipped with oiled eccentric gearing and the negative yarn let-off system.
Needle Type: Block latch needle, individual latch needle or Compound needle
Gauge: E3, E6, E7, E8, E9, E12, E14, E16, E18
Machine Parameters
Type Size (L×W×H) Weight (Kg) Power (KW) Speed (rpm)
SRCA-135 4300×2200×2700 4700 3 200-530
SRCA-150 4900×2200×2700 5000 3 200-530
SRCA-180 6100×2200×2700 7500 5.5 200-530
SRCA-220 7300×2200×2700 9000 5.5 200-530
SRCA-260 8200×2200×2700 11000 7.5 200-480
SRCA-340 10300×2200×2700 14000 11 200-450
Applications
Shade net is a type of netting material used to provide shade and protection from excessive sunlight. Commonly used in agricultural settings, nurseries, gardens, and outdoor areas to create cooler, controlled environments. Shade net machines produce nets that protect from harsh weather, regulate temperature, and shield crops from excessive sunlight. Recent advancements focus on automation, durability, and customization.
Primary Purposes
  • Protection from Sunlight: Reduces sunlight intensity to prevent overheating of crops, plants, or animals
  • Temperature Control: Filters sunlight to maintain lower temperatures for optimal growth conditions
  • Wind and Dust Barrier: Acts as windbreak to reduce wind speed and prevent dust in sensitive areas
Product Images
High-Speed Shade Net Making Machine with Customizable 135"-260" Width and Modern UV Protection Technology 0 High-Speed Shade Net Making Machine with Customizable 135"-260" Width and Modern UV Protection Technology 1 High-Speed Shade Net Making Machine with Customizable 135"-260" Width and Modern UV Protection Technology 2 High-Speed Shade Net Making Machine with Customizable 135"-260" Width and Modern UV Protection Technology 3
Technical Support and Services
Our company provides comprehensive technical support and service for our Shading Net Making Machine, including:
  • Information and troubleshooting assistance
  • Software and hardware upgrades
  • Installation and maintenance services
  • Technical advice and guidance
  • Parts and accessories replacements
We also provide on-site service for complex repairs and maintenance. Our team of highly qualified technicians can help with any technical problems or adjustments needed.
High-Speed Shade Net Making Machine with Customizable 135"-260" Width and Modern UV Protection Technology 4 High-Speed Shade Net Making Machine with Customizable 135"-260" Width and Modern UV Protection Technology 5
Packing and Shipping
We ensure the safety of all goods during packing and shipping processes.
High-Speed Shade Net Making Machine with Customizable 135"-260" Width and Modern UV Protection Technology 6 High-Speed Shade Net Making Machine with Customizable 135"-260" Width and Modern UV Protection Technology 7
Frequently Asked Questions
What is the output of shading net making machine?
Depending on machine working width and net technical specifications, output is approximately 500-1000KG/24h.
How much space needed to set up a shading net production line?
A small-scale production line requires at least 100-200 square meters, while larger lines may require several thousand square meters. Space considerations include each machine, plus storage for raw materials and finished products.
How many kinds of shading net can be produced by rascheal warp knitting machine?
Depending on materials used, four types of shade nets can be produced: mono+mono yarn shading net, mono+flat yarn shading net, mono+flat yarn shade net, and Al+pet yarn shade net.
Are the machines customizable for different net specifications?
Yes, modern shading net making machines are customizable to produce nets of various sizes, mesh configurations, and materials. Machine settings can be adjusted to meet specific shading requirements.
What types of shading nets material can be made with these machines?
Generally, shading net material is HDPE, with some nets using AL and PET materials.
Are there any special skills required to operate the machine?
Operating a shading net making machine requires training for optimal performance. Manufacturers provide training sessions and manuals to guide operators through setup, operation, and maintenance.
