E14 Knot Type Shading Net Machine Raschel Net Making Machine with Online Support

$45,000/sets 1-7 sets
Price
E14 Knot Type Shading Net Machine Raschel Net Making Machine with Online Support
Features Gallery Product Description Request A Quote
Features
Specifications
Features: Fast And High Production
Video Outgoing-inspection: Provided
Machinery Test Report: Provided
Core Components: Motor
Automatic Grade: Manual
Production Capacity: 80%
Place Of Origin: Jiangsu, China
Brand Name: Chenye
Voltage: According To Buyer Country
Power(W): According To Buyer Country
Dimension(l*w*h): Different Size
Warranty: ONE YEAR
Product Name: Raschel Warp Knitting Machinery
Model: RS
Working Width: 110'',135'',150'',180'',220'',260'',340''
Knot Type: E6,E7,E8,E9,E12,E14
Bars: 2~6 Bars
After Warranty Service: Online Support
Local Service Location: India
After-sales Service Provided: Free Spare Parts
Applicable Industries: Farms, Restaurant, Food Shop, Printing Shops
Showroom Location: India, Spain
Marketing Type: Ordinary Product
Warranty Of Core Components: 1 Year
Condition: New
Application: Producing Net
Weight: 7000 KG
Port: Shanghai, Ningbo
Basic Infomation
Payment & Shipping Terms
Packaging Details: 40HQ Container.
Supply Ability: 15 Set/Sets per Month
Product Description
Product Description

Product Application

RS High Speed Single Needle Bar Raschel Machine

APPLICATION:This machine is used to produce knotless fishing net,protecting net ,purse net,garment net and shading net.
FEATURES:The machine is equipped with open cam gearing and 3-rollers positive yarn left-off system.


Usage:This machine is used to produce knotless fishing net,protecting net ,purse net,garment net and shading net.
Features:The machine is equipped with open cam gearing and 3-rollers positive yarn left-off system.

Needle Type:Compound needle,Latch Needle

Gauge:E1,E2,E3,E6, E9, E12, E18,E24

Bar Number:2~4

Nominal Width:135" 150" 180" 220" 260"

Machine Type
Machine Size
Machine Weight(kg)
Main Motor(KW)
Inching Motor(KW)
Speed(rpm)
RS-130
4300x1700x2300
4500
4
0.37
400-700
RS-150
5300x1700x2300
5000
5.5
0.37
400-700
RS-180
6100x1700x2400
7500
5.5
0.75
400-650
RS-220
7100x1700x2400
9000
5.5
1.5
400-650
RS-240
7600x1700x2400
11000
7.5
1.5
400-650
RS-260
8100x1700x2400
14000
11
1.5
400-650
E14 Knot Type Shading Net Machine Raschel Net Making Machine with Online Support 0
E14 Knot Type Shading Net Machine Raschel Net Making Machine with Online Support 1
E14 Knot Type Shading Net Machine Raschel Net Making Machine with Online Support 2
E14 Knot Type Shading Net Machine Raschel Net Making Machine with Online Support 3
Our Service

We will dispatch enginner to your factory to commissioning the machine and teach your workers how to opperate the machine.


E14 Knot Type Shading Net Machine Raschel Net Making Machine with Online Support 4
Packing & Delivery
E14 Knot Type Shading Net Machine Raschel Net Making Machine with Online Support 5
