Strong Net Mesh Fabric Making Machine For 100D Polyester Tricot Big Eye Hole Knitting

1SET
MOQ
USD25000-40000
Price
Strong Net Mesh Fabric Making Machine For 100D Polyester Tricot Big Eye Hole Knitting
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty: 1 Year
Condition: New
Product Name: Raschel Warp Knitting Machinery
Speed: 200-480rpm
Gauge: E2/E6/E7/E8/E9/E12
Computerized: YES
Color: Blue
Knot Type: Knotless
Highlight:

computerized lace making machine

,

cotton lace making machine

Basic Infomation
Place of Origin: Jiangsu, China (Mainland)
Brand Name: chenye
Certification: SGS
Model Number: SRCP
Payment & Shipping Terms
Packaging Details: Wooden Case
Delivery Time: 45Working Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10SETS/MONTH
Product Description

100D polyester tricot big eye hole knitting diamond strong net mesh fabric machine for bags pocket pol



SPECIFICATION

Usage:The machine can produce mosquito net,plaid net,
            purse net and chemical fiber garment net.
Features: The machine is equipped with open cam gearing,
                 the negative yarn let-off system.
Needle Type
Latch Needle
Gauge
E6, E7, E8, E9, E12, E14, E16, E18
Bar Number
2~6
Nominal Width
135" 150" 180" 220" 260"
Take-up Manner
2 rollers with friction drive,center shaft drive;
2 rollers with friction drive,separately-standing,
center shaft drive, separately-standing

Machine Type
Machine Size(L*W*H)(mm)
Machine Weight(Kg)
Motor Power(Kw)
Speed(row/minute)
Main Motor
Inching Motor
SRCP-135
4300*2200*2700
~4500
3
0.37
200-560
SRCP-150
4900*2200*2700
~5000
3
0.37
200-560
SRCP-180
6100*2300*2800
~7500
5.5
0.75
200-560
SRCP-220
7300*2300*2800
~9000
5.5
1.5
200-500
SRCP-260
8100*2300*2800
~11000
7.5
1.5
200-480







PRODUCTION PROCESS

Strong Net Mesh Fabric Making Machine For 100D Polyester Tricot Big Eye Hole Knitting 0



WHAT KIND OF NETS CAN BE MADE
Knitted mesh fabrics are also divided into two types, weft-knitted mesh fabrics and
warp-knitted mesh fabrics. Among them, warp-knitted mesh fabrics are generally
woven with West German high-speed warp knitting machines. The raw materials
are generally nylon, polyester, spandex, etc. The finished product has high elastic
mesh cloth, mosquito net cloth, laundry net, luggage net, hard net, sandwich net
cloth, licote, embroidered mesh, wedding net, square grid, transparent net, American
net, diamond net, jacquard net , lace and other mesh fabrics.

Strong Net Mesh Fabric Making Machine For 100D Polyester Tricot Big Eye Hole Knitting 1

Product Description

SRCP High Speed Single Needle Bar Raschel Machine

APPLICATION:This machine is used to produce mosquito net,
plaid net,purse net and chemical fiber garment net.

FEATURES:The machine is equipped with open camgearing ,
the negative yarn let-off system


Strong Net Mesh Fabric Making Machine For 100D Polyester Tricot Big Eye Hole Knitting 2

PACKAGING & SHIPPING

Packaging Details:The normal package is wooden box(Size: L*W*H).
If export to european countries,the wooden box will be fumigated.
If container is too tigher,we will use pe film for packing or pack
it according to customers special request.
Port :shanghai

Strong Net Mesh Fabric Making Machine For 100D Polyester Tricot Big Eye Hole Knitting 3



OUR SERVICES

  • The warranty period of all products sold by our company is one year,
    with lifelong technical service support.
  • User's workers can get free technical training in our company to
    ensure correct usage and maintenance of equipment.
  • We will arrange special personnel for periodic visits and remind
    users to maintain the equipment regularly.


FAQ

1. Q:Are you a factory or trading company?

A:We are a factory.

2. Q: How about the after-sale service?

A:We offer after-sale overseas service.
    Engineers available to service machinery overseas.
B:Any problem about our products, pls feel free to call our after-sale department,
   You'll get our prompt attention and solvement.

3. Q: What payment terms you accept ?

A: We accept L/C ,T/T,Western Union or other payments.
4. Q:Where is your factory located? How can I visit there?

A:Our factory is located in Changzhou City, jiangsu Province, China.

All our clients, from home or abroad, are warmly welcome to visit us!
